2''throat diameter
TN-BX5210
2''throat diameter
●51.6mm(2 in) CCAW VC
● 80 Watts RMS
● Titanium diaphragm
● 1KHz-20KHz response
● 108 dB sensitivity
● 8Ω nominal impedance
● Magnet 34Oz
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 2/50 in/mm |
| MAX Power | 160 Watts |
| RMS Power | 80 Watts |
| lmpedance | 8 Ohm |
| Frequency Response | 1K Hz–20k Hz |
| Sensitivity(1W/1m) | 108 dB |
| Voice Coi| Diameter | 2"/51.6mm |
| Wind|ing materia| | CCAW |
| Magnet | 34 Oz |
| Diaphragm materia| | Titanium diaphragm |
| MOUNTING/SHIPPING INFORMATION | |
| Overa|| Diameter | 5. 3/134 in/mm |
| Depth | 2. 4/62 in/mm |
| Net Weight | 2. 5 kgs |
| Shipping Weight(1 pc) | 2. 8 kgs |
| Shipping Box(1 pc) | 15. 2X14. 2X6.5 cm |
