English
1'' throat diameter
TN-BX4410
1'' throat diameter
●44.4mm(1.75 in) CCAR VC
● 60 Watts RMS
● Titanium diaphragm
● 1KHz-20KHz response
● 108 dB sensitivity
● 8Ω nominal impedance
● Magnet 33Oz
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1/25 in/mm |
| MAX Power | 120 Watts |
| RMS Power | 60 Watts |
| lmpedance | 8 Ohm |
| Frequency Response | 1K Hz–20k Hz |
| Sensitivity(1W/1m) | 108 dB |
| Voice Coi| Diameter | 1. 75"/44.4mm |
| Wind|ing materia| | CCAR |
| Magnet | 33 Oz |
| Diaphragm materia| | Titanium diaphragm |
| MOUNTING/SHIPPING INFORMATION | |
| Overa|| Diameter | 4. 7/120 in/mm |
| Depth | 2. 4/62 in/mm |
| Net Weight | 2. 2 kgs |
| Shipping Weight(1 pc) | 2.3 kgs |
| Shipping Box(1 pc) | 13X13X7.5 cm |
