English
1'' throat diameter
TN-BX3410
1'' throat diameter
●34.4mm(1.35 in) CCAW VC
● 40 Watts RMS
● Titanium diaphragm
● 1KHz-20KHz response
● 100 dB sensitivity
● 8Ω nominal impedance
● Magnet 13Oz
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1/25 in/mm |
| MAX Power | 80 Watts |
| RMS Power | 40 Watts |
| lmpedance | 8 Ohm |
| Frequency Response | 1K Hz–20k Hz |
| Sensitivity(1W/1m) | 100 dB |
| Voice Coi| Diameter | 1. 35"/34.4mm |
| Wind|ing materia| | CCAW |
| Magnet | 13 Oz |
| Diaphragm materia| | Titanium diaphragm |
| MOUNTING/SHIPPING INFORMATION | |
| Overa|| Diameter | 3. 5/90 in/mm |
| Depth | 2/50 in/mm |
| Net Weight | 0. 9 kg |
| Shipping Weight(1 pc) | 0.95 kg |
| Shipping Box(1 pc) | 9. 5X9. 5X5.5 cm |
