1'' throat diameter
DH450
1'' throat diameter
●44mm(1.75 in) CCAR VC
● 60 Watts RMS
● Titanium diaphragm
● 1K-20K Hz response
● 108 dB sensitivity
● 8Ω nominal impedance
● Magnet 33Oz
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1/25 in/mm |
| MAX Power | 120 Watts |
| RMS Power | 60 Watts |
| lmpedance | 8 Ohm |
| Minimum impedance | 5.5 Ohm |
| Frequency Response | 1K–20k Hz |
| Sensitivity(1W/1m) | 108 dB |
| Voice Coil Diameter | 1.75/44 in/mm |
| Winding material | CCAR |
| Diaphragm material | Titanium |
| Former Material | Kapton |
| Diaphragm Shape | Dome |
| Phase Plug Design | Annular |
| Magnet |
33 Oz 120x50x20 mm |
| MOUNTING/SHIPPING INFORMATION | |
| 90°Mounting Holes Diameter(4xM6) | 2.2/57 in/mm |
| Overall Diameter | 4.7/120 in/mm |
| Depth | 2.4/62 in/mm |
| Net Weight |
2.2/4.85 kgs/lb |
| Shipping Weight(1 pc) | 2.3/5.07 kgs/lb |
| Shipping Box(1 pc) |
13x13x7.5 cm 5.11x5.11x2.95 in |
