10''LF Loudspeakers
10LW350N
10''LF Loudspeakers
●600W RMS capacity
●89 mm(3.5 in) inside-outside ALR voice coil
● 108-4000 Hz response
● 97 dB sensitivity
● 8Ω nominal impedance
● Neodymium
| THIELE SMALL PARAMETERS | |
| FS | 108 Hz |
| Vas | 6.85 dm³ |
| RE | 4.8 ohm |
| Qms | 6.1 |
| Qes | 0.37 |
| Qts | 0.35 |
| BL | 22.9 T/m |
| MMS | 58.2 grams |
| Xmax | 4.1 mm |
| Sd | 363 cm² |
| Efficiency | 2.294 % |
| EBP | 291 |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 10/254 in/mm |
| MAX Power | 1200 Watts |
| RMS Power | 600 Watts |
| lmpedance | 8 Ohm |
| Resonance(natural) Frequency | 108 Hz |
| Frequency Response | 108 Hz–4000 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 3.5/89 in/mm |
| Winding material | ALR(inside-outside) |
| Former material | Glass Fiber |
| Magnet |
Neodymium |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 10.4/265 in/mm |
| Bolt Circle Diameter | 9.6/245 in/mm |
| Baffle cutout Diameter | 9/228 in/mm |
| Depth | 5.6/143 in/mm |
| Net Weight | 4.2/9.26 kgs/lb |
| Shipping Weight | 4.8/10.58 kgs/lb |
| Shipping Box |
29X29X16 cm 11.42x11.42x6.30 in |
